FEYNLAB® PPF & VINYL V3

Installations Vejledning

APPROVED SURFACES
APPROVED SURFACES FOR APPLICATION – DO NOT apply to unapproved surfaces*

• Vinyl & Vinyl Wrapped Surfaces
• Paint Protection Film (PPF or Clear Bra)

*The use of Feynlab products on any surface not explicitly listed in the instruction booklet is done at the user’s own risk. If damage occurs to the surface as a result of using the product on an unlisted surface, we will not be held liable for any such damage.
Although PPF & Vinyl will not affect the self-healing of the PPF, it is best to check with the manufacturer of the film for potential warranty issues caused by adding a third-party product.

INCLUDED

1. 30ml (1oz) FEYNLAB® PPF & VINYL V3
2. 1 Microfiber Applicator Pad

CAUTIONS
Always wear respirator & gloves during application. Ensure application area is free of loose contamination.


PREPPING THE PAINT PROTECTION FILM

Thoroughly clean the surface using FEYNLAB® PURE WASH or FEYNLAB® PURE RINSELESS. For best adhesion of PPF & VINYL 3.0, perform a final wipe down/cleaning of the surface with FEYNLAB® PRIME. Dilute by using ¼ oz to 32 oz of distilled water. If PRIME is not available, the next best option would be FEYNLAB® PANEL PREP.

DIRECTIONS

Prior to application, place vehicle in a well-lit, temperature-controlled 50°F-85°F (10°C-30°C), & contamination free environment. Make sure you have plenty of new microfiber towels (4 or more) and plenty of lighting.
Begin by shaking PPF & VINYL 3.0 vigorously for 30 seconds.
Inspect the neck of the bottle for any hardened coating crystals. Carefully clean the neck of the bottle with a microfiber towel if any appear, as these can drop on to your applicator pad, and scratch the surface during application.

PAINT PROTECTION FILM APPLICATION INSTRUCTIONS

1. Apply enough PPF & VINYL 3.0 to a microfiber applicator to fully cover a single panel such as a door or half a hood.
2. Make a “+” (plus) sign with product in the middle of the panel, then wipe around the boundaries of the section creating a frame.
3. Next, fill in the framed area with light circular motions, slightly overlapping previous spots. After full panel coverage, switch to horizontal overlapping lines to even the product out on the surface.
4. After application, step back and look for any areas missed or those with excess product. If found, smooth out evenly with the applicator. This will ensure even drying across the panel.
5. Allow PPF & VINYL 3.0 to dwell on the PPF for 6-10 minutes, or until it is about 75% dry. Dwell time may vary depending on humidity and temperature. * Humid Climates 75%+ = Shorter Dwell time.
6. Wipe off PPF & VINYL 3.0 following same pattern of application, using two clean microfiber towels. Towel A (left hand) will remove the majority of coating residue. Towel B (right hand) will remove any remaining residue, revealing a crystal-clear surface.

RECOMMENDED MAXIMUM AREA OF APPLICATION

The area of application varies depending on PPF manufacturer and temperature and humidity. We suggest starting with 1 panel at a time. Always perform a test spot to determine the appropriate manageable area of application.

PREPPING THE VINYL SURFACES

Thoroughly clean the surface using FEYNLAB® PURE WASH or FEYNLAB® PURE RINSELESS. For best adhesion of PPF & VINYL 3.0, perform a final wipe down/cleaning of the surface with FEYNLAB® PRIME. Dilute by using ¼ oz to 32 oz of distilled water. If PRIME is not available, the next best option would be FEYNLAB® PANEL PREP.

DIRECTIONS

Prior to application, place vehicle in a well-lit, temperature-controlled 50°F-85°F (10°C-30°C), & contamination free environment. Make sure you have plenty of new microfiber towels (4 or more) and plenty of lighting.
Begin by shaking PPF & VINYL 3.0 vigorously for 30 seconds.
Inspect the neck of the bottle for any hardened coating crystals. Carefully clean the neck of the bottle with a microfiber towel if any appear, as these can drop on to your applicator pad, and scratch the surface during application.

VINYL APPLICATION INSTRUCTIONS

1. Apply enough PPF & VINYL 3.0 to a microfiber applicator to fully cover a single panel such as a door or half a hood.
2. Make a “+” (plus) sign with product in the middle of the panel, then wipe around the boundaries of the section creating a frame.
3. Next, fill in the framed area with light circular motions, slightly overlapping previous spots. After full panel coverage, switch to horizontal overlapping lines to even the product out on the surface.
4. After application, step back and look for any areas missed or those with excess product. If found, smooth out evenly with the applicator. This will ensure even drying across the panel.
5. Allow PPF & VINYL 3.0 to dwell on the vinyl surface for 5 minutes.
6. Wipe off PPF & VINYL 3.0 following same pattern of application, using two clean microfiber towels. Towel A (left hand) will remove the majority of coating residue. Towel B (right hand) will remove any remaining residue, revealing a crystal-clear surface.
7. If there is any noticeable shadowing after dry wiping the surface, very lightly mist a microfiber towel with water and wipe clear.

RECOMMENDED AREA OF APPLICATION

Varies depending on Vinyl manufacturer and temperature and humidity. We suggest starting with 1 panel at a time. Always perform a test spot to determine the appropriate manageable area of application.

SHELF LIFE
UNOPENED: 2 years // OPENED: 3 months (in a normal, climate-controlled environment).
